10 wheels 6X4 SHENHU brand HLQ5250GPSD 16000L water tank truck

Factory brand: SHENHU

MODEL: HLQ5250GPSD

Tank volume: 16000L

Tank material: carbon steel

Description

★★★★★Function And Introduction:

10 wheels 6X4 SHENHU brand HLQ5250GPSD 16000L water tank truck (also called 16000L water tank truck, water spraying truck, stainless steel water truck, 20M3 water tank truck, water tank truck, water transport truck, water hauling truck, clean water truck, drinking water truck, water tanker truck, water lorry) is used to transport and supply water,whatever industrial or agriculture water ,widely used in construction engineering ,farm irrigation,draught relief,etc.

The tank material includes stainless steel and carbon steel , if you use this truck to transport drinking water ,we advice you choose the 304 stainless steel tank.

1.Equipped with high power self-suction water pump that characterized by high pressure and fast speed suction.
2. Equipped with front, rear and side sprinklers and high position sprinkler, and rear working platform.
3.The water cannon which is installed on the working platform can rotate by 360 degree and the water flow can be adjusted into various rain shape. There are straight shape, heavy rain, moderate rain and drizzle etc. The max range can reach 30M.
4.Equipped with fire coupling, flow valves, filter screen and water level gauge.
5.According to customers' request, the crane, high working platform and spraying machine also can be equipped.

★★★★★Product Parameter:

10 wheels 6X4 SHENHU brand HLQ5250GPSD 16000L water tank truck
Basic Information
Outline size(L×W×H) (mm)	1050024953500		Tank volume：		16000L
Rated load(kg)	16000		Empty mass (Kg)：		9800
GVW(kg)	25800		Emission Standard		EURO 2
Gearbox	10-Speed
Engine Information
Engine model	WP12.400E201		Engine brand	SINOTRUK WEICHAI
Power/displacement (HP/CC)	400HP/ 11596CC		Type	Diesel engine
Cylinder arrangement	Inline six-cylinder		Rated speed:	1900rpm
Maximum torque:	1920N.M		Maximum torque speed:	1000-1400 rpm
Compression ratio:	17：01		Engine type:	Turbocharged, water-cooled, four-stroke, direct injection
Chassis Information
Wheelbase(mm)：	4350+1300		Axle load(kg) F/R			6500/10000/10000
Tire	12.00R22.5 PR18		Max speed (km/h)：			105
Front suspension(mm)	1440		Rear suspension(mm)			2210
Front track(mm)	2040		Rear track(mm)			1860/1860
Approach angel(°)	23		Departure angle(°)			16
Steering	Power steering		Brake			ABS‑equipped Air‑Hydraulic Braking
Cabin	Straight head ,single row with bed,3 people with Air-condition, ABS
Special function
WATER pump model	60/90 model	WATER pump material					Carbon steel
flow	1000L/MIN	range					Max 45M
Pump rotational speed	1350 r/min	Shaft power					7.5kw

Tank capacity(L)	16000L	Tank material					Carbon steel
Configuration	1. Equipped with high power self-suction water pump that characterized by high pressure and fast speed suction. front, rear and side sprinklers 2. Equipped with fire coupling, flow valves, filter screen and water level 3. 3 Compartments
Trade terms
Payment terms	40% by T/T in advance, 60% by T/T before delivery
Package	Waxing before delivery
