10 wheels DONGFENG 50TONS dumper truck （DFH3250A10)

Model: DFH3250A10 (Euro 3 series configuration)

Loading cpacity : 50tons

Container size: 5400*2300*1500mm

Description

10 wheels DONGFENG 50TONS dumper truck (dumper truck, tipper truck, engineering dump truck, 50tons dump truck, dumping truck ,dumper truck,tipper truck ,wagon tremie, ISUZU DUMP TRUCK ,Side-turn tipper, tipper and lorry, heavy duty tipper truck, sand dump truck, diesel dump truck, sludge tipper, side-tip dumper, mining dump truck , project vehicles, construction vehicle ) is used to transport Stone, sand, mud and other engineering materials,This kind of engineering vehicle is a special truck for loading, shifting and off-loading materials around a building site.

Based on the construction site and urban road driving, it has a series of products of heavy load type, composite type and urban construction slag type.

6*4 DONGFENG dump trucks are characterized by strong power and efficient transportation, and has passed thousands of industrial verification experiment.After three years of practice and improvement, the power system, steering system and braking system have been comprehensively optimized and improved, which is more suitable for all kinds of heavy loads and complex working conditions.It has the obvious advantages of high bearing capacity, high reliability, high safety and high economy.

★★★★★Our Service And Advantage :
1. High quality 6*4 chassis with super powerful SINOTRUK WEICHAI 380HP engine ,ensure best driving performance
2. Stable performance, reliable brands engine, Fast brand gearbox, safer Wheel-side reduction axle with large load capacity , Powerful power output to achieve multi-working-condition.
3. Rational structure ,High strength van body ,large capacity, solid durable
4. Modular designed chassis, neat arrangement highly universalizable. Meanwhile, the reliability and convenience of maintenance have been improved.

5. Our products through the ISO9001 ,national CCC certification , quality assurance.

★★★★★Product Parameter:

	Vehicle Model			DFH3250A10 (Euro 3 series configuration)
Mass parameter	Curb weight			13500kg
	Rated load			50000kg (Based on the road condition)
Performances	Max Speed			90km/h
	Min. turning diameter			20m
	Grade ability			≥30%
	Hill-hold ability			≥20%
	Fuel Consumption			38L
	Fuel Tank			400L
Dimensions	Overall dimensions		Length	8500mm
			Width	2500mm
			Height	3600mm
	Wheelbase			4000+1350 mm
	Wheel tread		Front	2010mm
			Rear	1880mm
	Min. Clearance			249mm
	Approach angle			23°
	Departure angle			25°
	Front overhang			1532mm
	Rear overhang			1902mm
	Cargo size			5400×2350×1500mm
Cabin	Model			DONGFENG DALISHEN
	Passengers			3
Engine	Model			WP10.380
	Displacement			9.726L
	Output power			380HP
	Mix torque speed			1460N·m
Clutch	Model			Φ430 Pull type diaphragm spring clutch
	Operation			Hydraulic manual
Transmission	Model			12JSD160T
	Manipulation			Flexible shaft
	Forward ratio			15.53/12.08/9.39/7.33/5.73/4.46/3.48/2.71/2.1/1.64/1.28/1
	Reverse ratio			14.86/3.33
Driven axle	Model			Double 18T
	Ratio			5.73
	Brake type			Drum type
	Differential lock			Differential lock between axles and wheels
Front axle	Model			6.5t
	Brake type			Drum type
Tire	Rim			9.75×22.5/8.50V-20
	Tire			12.00R20-18PR
Frame	Type			Straight beam of equal width
	Main beam			320×90×8 mm
	Auxiliary beam			304×90×8 mm
	Width of chassis structure			865mm
Suspension	Front	Type		Multi-spring
		Amount of spring plate		10
	Rear	Type		Multi-spring
		Amount of spring plate		13
Steering	Steering type			Φ130 Circulating ball type hydraulic power
	Ratio			23.27
	Max pressure of pump			17MPa
Brake	Rated working pressure			1MPa
	Driving brake			Dual circuit pneumatic braking
	Parking brake			Spring energy storage air brake
	Assistant brake			Engine exhaust brake
Electric System	Voltage			24V
	Generator power			1.96kw
	Battery voltage and Capacitance			2×12V/165Ah

★★★★★Product Display :

★★★★★FAQ PARTS :

Q: How about Packaging?
A:In general , these trucks will be waxing before deliver to port ,and we can also package vehicles
according to your request.
Q: How about shipping ?
A:Big size trucks always shipping by RORO or bulk ship or flat bed container or open top container ,small type can shipping by container ,please contact us to get a shipping quotation.
Q:How about the warranty?
A: One year
Q: Do you have ISO certificate ?
A: Yes , we have ,please contact us to get our certifications.
Q: How about the delivery time ?
A: Most of our trucks are all have in stock ,we can delivery to you within 7 days ,if specially ordered ,we always need around 30 days for production.
Q: How about your product After-sales service system ?
A: Our main export country have accepted after-sales service, some of country used the third department service.
Q: Do you accept Custom orders ? What's your MOQ order?
A: Yes,we do ,our MOQ is 1set.
Q: What's the payment terms ?
A: By T/T or L/C at sight.
Q: Which country do you have exported to ?
A: We have exported to many countries,such as Albania,Algeria,Angola,
Afghanistan,Congo,Cameroon,Chile,Cuba,Guinea,Indonesia,Iran,Iraq,Jamaica,Jordan,Kenya,Kuwait,Kazakhstan,

Uzbekistan,Tajikistan,Turkmenistan,Laos,Libya,Malaysia,Maldives,Mexico,Morocco,Myanmar,Mongolia,New Zealand,Nigeria,Peru,Philippines, Qatar,Saudi Arabia,Singapore,Sudan,South Sudan,Tanzania,Thailand,Togo, Tunisia,Venezuela,Zambia etc.
